Semiconductor Packaging: Advanced packaging processes including BGA, CSP, and Flip-Chip
Power Electronics: Thermal filler for IGBT and MOSFET modules
LED Packaging: Improves heat dissipation and light efficiency of LED devices
5G Communications: High-frequency substrates and high-power RF component packaging
Electronic Ceramics: HTCC/LTCC substrates and insulation layers
High Purity: 99.5% purity with ultra-low metal impurities, meeting semiconductor-grade requirements
Perfect Sphericity: ≥95% sphericity for improved packing density and flowability
Superior Thermal Conductivity: ≥30 W/m·K thermal conductivity for effective chip junction temperature reduction
Low Alpha Radiation: ≤0.01 cph/cm² to prevent soft errors and enhance device reliability
Adjustable Particle Size: 2-50μm options available to suit various packaging processes
Packaging: 25kg/bag (customizable)
Storage: Store in cool, dry conditions away from moisture and contaminants
Electronic-Grade Specialization: 15 years of expertise in high-purity electronic materials
Strict Quality Control: ISO 9001/IATF 16949 certified
Customization Service: Tailored particle size and surface modification options
Global Supply: Serving 100+ semiconductor industry clients
Project | Related indicators | Explain |
Purity | A1.03 | More than 99% |
Impurities | Na,0 | Can be as low as below 300ppm |
Appearance | 0-A1z03 content | Up to 90% or more |
Particle Size Distribution | D50 | Optional within 2um-50um |
Di₀0 | Can be as low as 10um or less | |
Particle size distribution | Adjustments can be made based on the typical distribution according to the requirements of the palace household, including multi-modal distribution and narrow distribution |
Project | Unit | Typical values |
Appearance | / | White pink wood |
Particle Shaped Ni | / | Spherical |
Density | kg/m³ | 3.7×103 |
Mohs Hardness | / | 6-9 |
Dielectric Constant | Er | 9 |
Dielectric Loss | lgδ | 0.0003 |
Linear expansion coefficient | 1/K | 0.7x10-6 |
Thermal conductivity | W/Kam | 30 |
